LR80
The LR80 Handrail offers robust performance and sleek design for modern architectural applications. With a 2 3/8” base width, 3 1/8” height, and 2 5/8” glazing depth, it supports glass panels up to 31 1/2” high and 47 1/4” wide, in 1/2” or 5/8” thickness. Successfully impact- and push-tested, it’s ideal for heavy-duty residential, commercial, and high-end projects.
LR100
The LR100 Handrail is built for high-performance architectural use, combining strength with modern aesthetics. With a 2³/₈” base width, 3⁷/₈” height, and 3⁵/₁₆” glazing depth, it supports glass up to 47¹/₄” in both height and width. Compatible with ¹/₂” and ⁵/₈” tempered or laminated glass, and tested for impact and push resistance, it’s ideal for residential, commercial, and public spaces demanding structural integrity.
LR116
The LR116 Handrail delivers maximum strength and bold architectural presence. With a 3 1/8” base, 4 9/16” height, and 4 1/4” glazing depth, it supports glass up to 47 1/4” high and 55 1/8” wide in 1/2” or 5/8” thickness. Rigorously impact- and push-tested, it’s ideal for large-scale commercial, residential, and high-rise projects.
Premium Features
Slimline design
Narrow frames for a refined, modern aesthetic.
Shock resistance
Engineered to absorb shock and resist breakage.
Frameless clarity
Minimalist look with maximum transparency.
Seamless hardware
Concealed components for a clean, seamless finish.
Storm-ready
Tested to perform in high-wind conditions.
Inside the Frame
Technical Specifications
| LR80 | LR100 | LR116 | |
|---|---|---|---|
| Base Profile Width | 2.36 inch | 2.36 inch | 3.15 inch |
| Base Profile Height | 3.15 inch | 3.94 inch | 4.57 inch |
| Glazing Depth in Profile | 2.64 inch | 3.31 inch | 4.25 inch |
| Max. Glazing Railing Height | 31.5 inch | 47.25 inch | 47.25 inch |
| Max. Glazing Railing Width | 47.25 inch | 47.25 inch | 55.12 inch |
| Glazing Thickness | 0.47 inch | 0.63 inch | - |
Application Options
- Heavy-duty residential
- Commercial
- High-end projects
Glass Specs & Configurations
Discover a range of glass types engineered to meet aesthetic, performance, and safety requirements—each tailored to enhance the design and functionality of your project.
Glass Types
Insulation & Energy Efficiency
Premium Finishes
Choose from our standard color selection or customize your project with any RAL color or wood grain finishes. Our durable, powder-coated aluminum ensures long-lasting performance, weather resistance, and a flawless aesthetic.
9016
White
9006
Aluminum
9005
Jet Black
7021
Black Grey
1247
Bronze
9001
Cream
7006
Beige grey
7016
Anthracite
7040
Window Grey
9403-205
Maple
9403-205
Golden pine
9403-205
Red mahogany
Powder-coated
Anodized
Custom RAL colors
Wood-grain
